Thang nâng người 19m COMET

19 | 2 | 14 HQ



  • Max Working height 19 m
  • Max Lateral outreach 14 m
  • Basket floor 17 m
  • Capacity 250 Kg – 2 operators
  • Standard aluminum basket 1400x700x1100 mm
  • Hydraulic basket rotation 90°+90°
  • Stabilisation: n° 4 hydraulic outriggers
  • Rotation: 360° continuous
  • Controls: 100% hydraulic in low pressure
  • Minimum GVW 6,0 ton
  • Working area depending on truck GVW
Lượt xem : 1747
DESCRIPTION
  • Aerial platform made of high strength steel for boom maximum rigidity and maximum safety while working.
  • The telescopic boom is made of 3 elements (2 telescopic extensions). Hoses and pipes are positioned inside the boom structure for maximum protection against damages or accidental fall of tools, etc.
  • 100% hydraulic controls
  • Controls with proportional system in low pressure (25 BAR only) in the basket to allow gradual and accurate movements, and long-lasting life to the platform with maintenance costs reduced at minimum.
  • No need of any device to limit lateral outreach (100% SAFE)
  • Constant and gradual automatic leveling of the basket with independent hydraulic circuit
  • Electric power tap 230 V in basket
  • Engine start & stop from the basket
  • Closed outriggers warning light for driving safely
  • Hour-counter in the cabin
  • Aluminum basket. Also available the fiberglass basket insulated against accidental contacts with electrical power lines

PRODUCT SHEET

Aerial Platform Comet - New Eurosfilo HQ - 19 | 2 | 14 HQ
